P4/8 Led Transparent Film Screen Outdoor Front Service

Topbright Creation Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

P4/8 Led Transparent Film Screen Outdoor Front Service

Brand Name : TBC LED

Model Number : P4/8

Certification : FCC, CE, ROHS

Place of Origin : China

MOQ : 10sqm

Price : Negotiable

Payment Terms : T/T

Supply Ability : 1000 sqm per month

Delivery Time : 25 days

Packaging Details : Flight Cases

Type : Outdoor Transparent LED Screen

Pixel Pitch : P4/8-20mm

Cabinet Size : 1m Diameter

Service : Front Service

Weight : 7kg

LED Type : High Brightness SMD2121

Contact Now

LED Film screen--product features



1.Thin
• The screen is light in weight and has no pressure on the glass,
• Thickness: about 3mm, weight 3-6kg/ square meter

2. Transparent
• The structure is extremely simple, the permeability is high, does not affect the viewing line, and the permeability is as high as 85% or more

3. High flexibility
• The maximum unit size is limited to 960mm*3000mm,
• The maximum size and length of a single glass is 3 meters, without a power box in the middle.
• Can be bent and cut, not limited by size, can be flexibly designed according to customer needs Strong flexibility, can be attached to any curved glass/wall
4. Easy to install
• Easy to install, directly attached to the glass surface, and then just connect the signal and power supply

5. Large viewing angle
• Up to 140 degrees up, down, left, and right fields of view, no dead angle, no color cast, the image is always perfect and seamless

6. Cost saving
• Product installation does not require additional steel frame structure, does not need to change the appearance of ancillary buildings, effectively reducing transportation and installation costs









P4/8 Led Transparent Film Screen Outdoor Front ServiceP4/8 Led Transparent Film Screen Outdoor Front Service





LED film screen - product parameters



Project

Unit

parameter

parameter

parameter

parameter

Product No



DM4/8

DM6.5

D10

D20

light source model

SMD

2121

2121

2121

2121

Density

dot/m2

31250

23668

10000

2500

Module Size

mm

960(H)X256(W)

962(H)X208(W)

960(H)X320(W)

960(H)X320(W)

Screen compositon

High transparency,high temperature resistance,flame retardantPC

Weight

kg/m2

6

6

6

6

Permeability











Brightness

cd/m2

≥4000

≥5000

≥5000

≥3000

Refresh

Hz









Scan



stati

stati

stati

stati

Maximum power

W/m2









average power

W/m2

300

300

200

200

installation method











maintenance method



Pre/Post Maintenance

Brightness Level



256

Operating Voltage   DC5V

gray scale

bit

12- 16

IP

IP

IP30

Viewing angle

Degree

Horizontal≥150度, Vertical ≥ 150

Input voltage



degreesAC95V~240V

Operating temperature

°C

-20~65

Working humidity



10% ~90RH

service life

          1 00000 hours
